Centrifugal Pump | Spike UMA Piston Pump | VR Piston Pump
VR Lucky Hand-press Pump | Monkey-tail Hand-press Pump
Pump Applications
- Agriculture: water supply, pumping up, drainage
Pump Performance
- Pumping water up at high volume of water under suitable pressure. It can suction every kind of water without stucking of trash while it's working because of using impeller. It performs best for suction water into the well. In addition, it can be connected with either motor or engine.
Constructional Features
- Pump Body: Cast Iron
- Shaft: Carbon Steel
- Boost Compressing: To increase working efficiency of shaft and avoid running unevenly of engine, shaft has been compressed by the cast iron and brass boost for Kato Sery and Yammamoto Sery respectively.
- Suction cover with single impeller type
Series: 2 |
| 1st Sery: Kato VR Centrifugal Pump - 2 Sizes (KVR-2 & KVR-3) |
 |
Kato VR Centrifugal Pump KVR-2
Specifications:
| Water Volume |
400 litres/min
(23 m 3 /hr) |
| |
250 litres/min
(15 m 3 /hr) |
| Water Supply Distance |
9 metres |
| |
12 metres |
| Suction – Supply Pipe |
2 inches |
| Motor |
2 horse power |
| |
|
|
| Kato VR Centrifugal Pump KVR-3
Specifications:
| Suction – Supply Pipe |
3 inches |
| Water Volume |
750 litres/min
(45 m 3 /hr) |
| |
400 litres/min
(24 m 3 /hr) |
| Water Supply Distance |
10 metres |
| Suction – Supply Pipe |
13 metres |
| Motor |
3 horse power |
| |
|
|
| 2nd Sery: Yammamoto VR Centrifugal Pump - 2 Sizes (YVR-2 & YVR-3) |
 |
Yammamoto VR Centrifugal Pump YVR-2
Specifications:
| Water Volume |
200 liters/min (12m3/hr) |
| Water Supply Distance |
5 metres |
| Suction – Supply Pipe |
2 inches |
| Motor |
2 – 3 horse power |
| Impeller |
Turning Left |
|
 |
Yammamoto VR Centrifugal Pump YVR-3
Specifications:
| Water Volume |
300 liters/min (18m3/hr) |
| Water Supply Distance |
10 metres |
| Suction – Supply Pipe |
3 inches |
| Motor |
5 – 6 horse power |
| Impeller |
Turning Left |
|
Pump Application
- Agriculture: water supply, pumping up, drainage
- Home-used
Pump Performance
- This is a prototype pump, which has water supply booster. All pumps are manufactured under a perfect quality control system and high precision machines. The good design and
manufacture result in high efficiency, strength, righidity, accessibility and pleasing
appearance.
Sizes: 4 (R43-S & R43-S/1 // R65-G // R76-G // R103-G) |
 |
Spike UMA Piston Pump R43-S
Specifications:
| Water Volume |
1,700 litres/hr |
| Vertical Suction Distance |
13-15 metres |
| Suction – Supply Pipe |
1 inch |
| Piston |
43mm. |
| Cylinder |
Stainless Steel |
| Motor |
1/3 hp |
| |
|
Construction Features:
|
|
| Piston Rod |
Cast Iron |
| Shaft |
Stainless Steel |
| Valve Sheet |
Brass |
| Congested Ball Cover |
Brass |
| Helical Spring |
Stainless Steel |
| Valve Congested Screw |
Brass |
| Valve Plate |
Stainless Steel |
| Concentric |
Carbon Steel |
| Ventilator |
Brass |
| Prime Nut |
Brass |
| Pulley |
- |
|
 |
Spike UMA Piston Pump R43-S/1, R65-G
Specifications:
| |
R43-S/1 |
R65-G |
| Water Volume |
1,500 litres/hr |
6,000 litres/hr |
| Vertical Suction Distance |
13-15 metres |
13-15 metres |
| Suction – Supply Casting |
1 inch |
11/2 inches |
| Piston |
43 mm |
65 mm |
| Cylinder |
Brass |
Brass |
| Motor |
1/3 hp |
1 1/2hp |
| |
|
|
Construction Features: |
|
|
| Piston Rod |
Cast Iron |
Brass |
| Shaft |
Stainless Steel |
Stainless Steel |
| Valve Sheet |
Brass |
Brass |
| Congested Ball Cover |
Brass |
Brass |
| Coil Spring |
Stainless Steel |
Brass |
| Valve Congested Screw |
Brass |
Brass |
| Valve Plate |
Stainless Steel |
Brass |
| Concentric |
Carbon Steel |
Carbon Steel |
| Ventilator |
Brass |
Brass |
| Prime Nut |
Brass |
Brass |
| Pulley |
- |
B-Design*** |
| |
|
|
Spike UMA Piston Pump R76-G, R103-G
Specifications:
| |
R76-G |
R103-G |
| Water Volume |
7,000 litres/hr |
25,000 litres/hr |
| Vertical Suction Distance |
13-15 metres |
13-15 metres |
| Suction – Supply Pipe |
2 inches |
3 inches |
| Piston |
76 mm |
103 mm |
| Cylinder |
Brass |
Brass |
| Motor |
1 1/2 - 2 hp |
10 - 15 hp |
Construction Features:
| Piston Rod |
Brass |
Ductile |
| Shaft |
Stainless Steel |
Stainless Steel |
| Valve Sheet |
Brass |
Brass |
| Congested Ball Cover |
Brass |
Brass |
| Helical Spring |
Brass |
Brass |
| Valve Congested Screw |
Brass |
Brass |
| Valve Plate |
Brass |
Brass |
| Concentric |
Carbon Steel |
Ductile |
| Ventilator |
Brass |
Brass |
| Prime Nut |
Brass |
Brass |
| Pulley |
B-Design*** |
B-Design*** |
|
Remarks: ***B-Design pulley can use with either motor or engine |
|
 |
- Depth water suction type |
Pump Application
- Agriculture: water supply, pumping up, drainage
- Home-used
Pump Performance
- With the long haul portion and wider pump body, it is ideal for depth water suctions and boosts the water supply in far area.
Sizes: 5 (PVR49 // PVR53 // PVR65 // PVR 76 // PVR90) |
 |
VR Piston Pump
PVR - 49
Specifications:
| Water Volume |
3,000 - 3,600 litres/hr |
| Vertical Suction Distance |
13-15 metres |
| Suction – Supply Pipe |
1 inch |
| Piston |
49 mm |
| Cylinder |
Brass |
| Motor |
1/3 - 1/2 hp |
Construction Features:
| Piston Rod |
Cast Iron |
| Shaft |
Stainless Steel |
| Valve Sheet |
Brass |
| Congested Ball Cover |
Brass |
| Helical Spring |
Stainless Steel |
| Valve Congested Screw |
Brass |
| Valve Plate |
Stainless Steel |
| Concentric |
Carbon Steel |
| Ventilator |
Brass |
| Prime Nut |
Brass |
| Pulley |
- |
|
 |
VR Piston Pump
PVR - 53
Specifications:
| Water Volume |
3,500 - 4,500 litres/hr |
| Vertical Suction Distance |
13-15 metres |
| Suction – Supply Pipe |
1 inch |
| Piston |
53 mm |
| Cylinder |
Brass |
| Motor |
1/2 - 1 hp |
Construction Features:
| Piston Rod |
Brass |
| Shaft |
Stainless Steel |
| Valve Sheet |
Brass |
| Congested Ball Cover |
Brass |
| Helical Spring |
Stainless Steel |
| Valve Congested Screw |
Brass |
| Valve Plate |
Stainless Steel |
| Concentric |
Carbon Steel |
| Ventilator |
Brass |
| Prime Nut |
Brass |
| Pulley |
- |
|
 |
VR Piston Pump
PVR - 65
Specifications:
| Water Volume |
6,000 - 7,000 litres/hr |
| Vertical Suction Distance |
13-15 metres |
| Suction – Supply Pipe |
1 1/2 inches |
| Piston |
65 mm |
| Cylinder |
Brass |
| Motor |
1 - 11/2 hp |
Construction Features:
| Piston Rod |
Brass |
| Shaft |
Stainless Steel |
| Valve Sheet |
Brass |
| Congested Ball Cover |
Brass |
| Helical Spring |
Brass |
| Valve Congested Screw |
Brass |
| Valve Plate |
Brass |
| Concentric |
Carbon Steel |
| Ventilator |
Brass |
| Prime Nut |
Brass |
| Pulley |
B-Design*** |
Remarks: *** B-Design pulley can use with either motor or engine |
 |
VR Piston Pump
PVR - 76
Specifications:
| Water Volume |
9,000 - 10,000 litres / hr |
| Vertical Suction Distance |
13-15 metres |
| Suction – Supply Casting |
2 inches |
| Piston |
76 mm |
| Cylinder |
Brass |
| Motor |
1 1/2 - 2 hp |
Construction Features:
| Piston Rod |
Brass |
| Shaft |
Stainless Steel |
| Valve Sheet |
Brass |
| Congested Ball Cover |
Brass |
| Helical Spring |
Brass |
| Valve Congested Screw |
Brass |
| Valve Plate |
Brass |
| Concentric |
Carbon Steel |
| Ventilator |
Brass |
| Prime Nut |
Brass |
| Pulley |
B-Design*** |
Remarks: *** B-Design pulley can use with either motor or engine |
 |
VR Piston Pump
PVR - 90
Specifications:
| Water Volume |
18,000 - 21,000 litres/hr |
| Vertical Suction Distance |
13-15 metres |
| Suction – Supply Pipe |
2 inches |
| Piston |
90 mm |
| Cylinder |
Brass |
| Motor |
5 hp |
Construction Features:
| Piston Rod |
Brass |
| Shaft |
Stainless Steel |
| Valve Sheet |
Brass |
| Congested Ball Cover |
Brass |
| Helical Spring |
Brass |
| Valve Congested Screw |
Stainless Steel |
| Valve Plate |
Stainless Steel |
| Concentric |
Carbon Steel |
| Ventilator |
Brass |
| Prime Nut |
Brass |
| Pulley |
B-Design*** |
Remarks: *** B-Design pulley can use with either motor or engine |
 |
Pump Application
- Agriculture: water suction, water prime from well
into centrifugal pump, suction water for small to
medium fishery
-
Best suit in the condition of non-electricity supply
Pump Performance
-
Every side need to be turned with a lathe for the conjuction parts to create the vacuum in the purpose of water suction at the powerful force. Whereas it is light for the user to press the pump-handle. It is very ideal for water suction from artesian well for usage or
prime from artesian well to other kind of suction
pump.
Specifications
| Suction – Supply Pipe |
11/2 inches |
| Vertical Suction Distance: |
15 metres |
| Piston |
110 mm |
Construction Features
-
All parts made from the cast iron 100%, which provide the benefit of durable against the erosion of water and extend the long shelf life.
-
To stimurate the powerful water suction, the cylinder block has been consisted of an octagon pot and a
valve rubber to dam up the water and generate
vacuum inside the pump. (1)
-
The inner-cylinder made from real stainless steel. (2)
-
The discharge water (red coneshape) processes in three steps to proceed continuously water supply system. In addition, it has to connect into water supply pipe. (3)
|
|
 |
Pump Application
-
Agriculture: water suction from artesian well, water
prime for centrifugal pump
-
Best suit in the condition of non-electricity supply
Pump Performance
-
It is ideal for water suction from artesian well, which has several types of soil either sandy soil or fat clay. It can be used even in the grit-water because a piston that made from leather endures from erosion and piercing.
Construction Features
| - Piston: |
Real Leather |
| - Shaft: |
3/8 inches Straight Line-Steel; not bend while using |
| - Cylinder: |
It has been reamed evenly |
Sizes: 2 (No. 75 & 90)
Monkey-tail Hand-press Pump No.75
Specifications
| Suction – Supply Pipe |
1 1/2 inches |
| Vertical Suction Distance |
15 metres |
| Piston |
75mm. |
Monkey-tail Hand-press Pump No.90
Specifications
| Suction – Supply Pipe |
1 1/2 - 2 inches |
| Vertical Suction Distance |
15 metres |
| Piston |
90mm. |
|
|
|
